Terraelino Gesso

Product overview

Terraelino Gesso

Terrælino was born from the inspiration to create a symbiosis between earth and linen, a primitive element and a refined fabric. Natural materials that enrich each other, brought together by the craftsmanship of the designer searching for a new kind of surface.

The result is a warm and vivid material, defined in five colors in 6 sizes referring to the earth and four colors inspired by fruits and spices.
A material devised to inspire professionals and welcome any application.

    Faces

    Size: 120*240 cm

    Surfaces

    We offer the broadest range of surfaces.
    Terraelino Gesso is available in:
    • Naturale
    Discover more
    Naturale
    Absolute Matte
    • Naturale
    • Absolute Matte

    Sizes

    120x240cm
    80x160cm
    120x120cm
    60x120cm
    60x60cm
    30x60cm

    Thickness

    9 mm

    Specifications

    DIMENSIONS AND SURFACE QUALITY
    Technical feature Standard method ISO Nexion values Requirements
    SIZE < 1200 mm SIZE ≥ 1200 mm
    % mm % mm
    Width ISO 10545 - 2 ± 0,1 ± 0,8 ± 0,1 ± 1 ± 0,3%
    Length ± 0,1 ± 0,8 ± 0,1 ± 1,2 ± 0,3%
    Thickness ± 4 ± 0,5 ± 4 ± 0,5 ± 5,0%
    Straightness of Side ± 0,1 ± 0,8 ± 0,1 ± 1 ± 0,3%
    Rectangularity ± 0,1 ± 1,3 ± 0,1 ± 1,5 ± 0,3%
    Surface Flatness ± 0,1 ± 1,8 ± 0,2 ± 3 ± 0,4%
    Surface Quality 95% A minimum of 95% of the tiles are to
    be free from visible defects which can
    impair the appearance of a major area
    of tiles
    PHYSICAL PROPERTIES
    Technical feature Standard method ISO Nexion values Requirements
    Water Absorption ISO 10545 - 3 ≤ 0,5%,
    Individual 0,6%
    Modulus of Rupture ISO 10545 - 4 Min. 42 N/mm² Min. 35 N/mm²,
    Individual Min. 32 N/mm²
    Breaking Strength ISO 10545 - 4 Min. 1800 N Not less than 1300 N
    Moisture Expansion ISO 10545 - 10 0,02 mm/m -
    Surface abrasion ISO 10545-7 CLASS IV Minimum Class - II Report abrasion class and cycles passed
    Mohs Hardness of surface NA 7
    Coefficient of linear thermal
    expansion from ambient
    temperature to 100 °C    		 ISO 10545 - 8 6x10⁻ ⁶ K⁻¹ max As declared by the Manufacturer
    Thermal Shock Resistance ISO 10545 - 9 No damage
    Crazing Resistance:
    glazed tiles    		 ISO 10545 - 11 No damage for
    Min. 10 Cycles    		 Required
    Bulk Density ISO 10545 - 3 2,2 g/cc 2,2 g/cc
    Impact Resistance ISO 10545 - 5 0,55 As declared by the Manufacturer
    Frost Resistance ISO 10545 - 12 No change
    Slip Resistance ANSI A137,1
    DIN 51130    		 DCOF > 0,51
    R-10    		 As declared by the Manufacturer
    Small colour differences ISO 10545 - 16 No change Plain coloured tiles only where required
    GL: ∆E < 0,75
    UGL: ∆E < 1,0
    CHEMICAL PROPERTIES
    Technical feature Standard method ISO Nexion values Requirements
    Resistance to staining ISO 10545 - 14 Class 4 Minimum Class 3
    Resistance to household
    chemicals and swimming pool
    salts    		 ISO 10545 - 13 Minimum A Minimum B
    Resistance to acids & alkalis Minimum B As declared by the Manufacturer
